Digital Solutions AF08
Audio Follow Control for Yamaha Digital Audio Mixers
02R96, DM1000, DM2000 and 02Rv2
Television production galleries and outside broadcast trucks can now enjoy fully integrated and automated audio-follow mixing with Yamaha's economical range of digital audio mixers. The Digital Solutions AF08 interface provides effective control using industry standard video switcher tally and under monitor tally signaling including MPK and GVG protocols
Under video switcher tally control, the mixer operates like a video switcher - opening the right faders at the right time. Individual mixes and fade out times can be quickly assigned for each tally.
A GVG CP3864 panel is used to provide immediate visual indication of currently active tallies and to enable easy mix assignment and local mix control.
The proven combination of the AF08 and these Yamaha digital mixers takes the hard work out of managing live audio mixing, whilst the compact design reduces fly-away shipping weight and space requirments.
The AF08 interface
for affordable, digital, audio follow mixer operation:
- Video Switcher tally follow operation
- Moving faders indicate audio levels and crossfade progress
- Automatic monitoring of mix assign buss
- Up to 96 digital or 40 analogue input channels ²
- Analogue and Digital stereo outputs
- Analogue and Digital Multi-buss outputs ²
- Audio levels stored and recalled
- Simple serial connections between edit controller BVE02 and mixer
- The mixer’s standard features remain uncompromised and available at all times
- Protocols: MPK, GVG and Yamaha "To Host" MIDI over RS422
- Connections: 9 pin D-Types - to editor, to mixer, BNC - Video Sync Input; DC - PSU
- LED indication of interface and serial link status
- Power Supply: External 8-12 Volt DC
- Dimensions: 282mm x 38mm x
220mm
¹ Subject to this feature being supported by the video edit controller
² Subject to mixer options being fitted
